Mapon Expert

A multi-purpose tracking device with high precision and a variety of interfaces for connecting accessories. There are two different devices available - Mapon Expert (4G and M1) and the new Mapon Expert 2 (4G) that provides additional interfaces and BLE technology support.

Ordering and installing

This is not an actual order form. Use it to receive the quotation for the specified amount of Mapon Expert devices. Our client consultants will get in touch with you and help to find the best solution for your business.

Ask an expert

About the product

Mapon Expert is a precise multi-purpose GPS tracking device with a wide set of functions and compatibility options. A great choice for professional fleet management.

Main features

Standalone mode with intelligent memory control, if connection with server not available
Intelligent data acquisition and transfer algorithm via 2G/3G/4G mobile networks depending on model
Smart data roaming algorithm
Realtime GPS and sensor data acquisition and transfer
Restart button
Interfacing to vehicle on-board systems
Internal 3-axis accelerometer
Raivis Bondars

State-of-the-art hardware

Raivis Bondars, Mapon Export Manager

Mapon Expert is a state-of-the-art device. It has a wide set of functions that are useful in standard cases as well as for custom solutions and integrations. We suggest Mapon Expert to clients who need professional solutions, including custom integrations. Mapon Expert supports integrations with refrigeration unit industry leaders Carrier and ThermoKing, as well as a variety of other telematics system providers. Mapon Expert enables you to use all features of the Mapon platform - including remote digital tachograph download, fuel control and advanced driving behaviour. We have developed this device in-house, which means that we can quickly react to any problems or errors that may arise and also create very advanced customized solutions for your business needs. It definitely is a premium product with high quality and rich set of features.

General

Size and weight

Height: 101 mm
Width: 123 mm
Depth: 22 mm
Weight: 140 g

Memory

64Mbit Flash memory

Power and battery

Li-ion backup battery 700 mAh
Operating voltage 10V to 30V DC
Average current consumption 250 mA

Interfaces

4 digital inputs (max 30V)
4 analog inputs 0 to 30V
SMA connector for GPS antenna
1-wire input (up to 6 devices)
2 CAN bus interfaces
3 RS-232
USB port
1 digital output

GNSS/Cellular

4G LTE CAT 1

LTE FDD: B1/B3/B7/B8/B20/B28A
GSM/EDGE: B3/B8

LTE CAT M1

LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/ B18/B19/B20/B25/B26/B28
LTE TDD: B39
EGPRS: 850/900/1800/1900 MHz

Location

GPS, GLONASS, Galileo, QZSS
Acquisition: -149dBm
Tracking: -167dBm
Reacquisition: -161dBm

Other

Status indicator

LED

Environmental requirements

Operating temperature: -40° to 85° C
Relative humidity: 5 to 95%
Non-condensing

Standard set

Mapon Expert
External GPS antenna
Documentation

General

Size and weight

Height: 101 mm
Width: 123 mm
Depth: 22 mm
Weight: 154 g

Memory

64Mbit Flash memory

Power and battery

Li-ion backup battery 700 mAh
Operating voltage 7V to 30V DC
Average current consumption 80 mA

Interfaces

Digital inputs

4 digital inputs (max 30V)
4 analog inputs 0 to 30V
3 CAN bus interfaces
3 RS-232
K-Line interface
RS-485 interface
1-wire input (up to 6 devices)
3 digital outputs
SMA connector for GPS antenna
USB port

GNSS/Cellular

4G LTE CAT 1

LTE FDD: B1/B3/B7/B8/B20/B28A
GSM/EDGE: B3/B8

Location

GPS, GLONASS, Galileo, QZSS
Acquisition: -149dBm
Tracking: -167dBm
Reacquisition: -161dBm

BLE

BLE 5.2

Other

Status indicator

LED

Environmental requirements

Operating temperature: -40° to 85° C
Relative humidity: 5% to 95%
Non-condensing

Standard set

Mapon Expert 2
External GPS antenna
Documentation
